import numpy as np

import torch
import torchvision

from torch.utils.data import Dataset
from torchvision import datasets, transforms

print(torch.__version__)
print(torchvision.__version__)

2.3.1+cu121
0.18.1+cu121

transform = transforms.Compose([
    transforms.ToTensor(),
])

train_data = datasets.FashionMNIST(root='data',
                                   train=True,        # 학습용 데이터셋 설정(True)
                                   download=True,
                                   transform=transform     # 정규화
                                  )

Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/train-images-idx3-ubyte.gz
Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/train-images-idx3-ubyte.gz to data/FashionMNIST/raw/train-images-idx3-ubyte.gz

100%|██████████| 26421880/26421880 [00:00<00:00, 45746159.06it/s]

Extracting data/FashionMNIST/raw/train-images-idx3-ubyte.gz to data/FashionMNIST/raw

Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/train-labels-idx1-ubyte.gz
Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/train-labels-idx1-ubyte.gz to data/FashionMNIST/raw/train-labels-idx1-ubyte.gz

100%|██████████| 29515/29515 [00:00<00:00, 6784024.69it/s]

Extracting data/FashionMNIST/raw/train-labels-idx1-ubyte.gz to data/FashionMNIST/raw

Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/t10k-images-idx3-ubyte.gz
Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/t10k-images-idx3-ubyte.gz to data/FashionMNIST/raw/t10k-images-idx3-ubyte.gz

100%|██████████| 4422102/4422102 [00:00<00:00, 8475887.31it/s]

Extracting data/FashionMNIST/raw/t10k-images-idx3-ubyte.gz to data/FashionMNIST/raw

Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/t10k-labels-idx1-ubyte.gz
Downloading http://fashion-mnist.s3-website.eu-central-1.amazonaws.com/t10k-labels-idx1-ubyte.gz to data/FashionMNIST/raw/t10k-labels-idx1-ubyte.gz

100%|██████████| 5148/5148 [00:00<00:00, 18470724.54it/s]

Extracting data/FashionMNIST/raw/t10k-labels-idx1-ubyte.gz to data/FashionMNIST/raw

test_data = datasets.FashionMNIST(root='data',
                                  train=False,        # 검증용 데이터셋 설정(False)
                                  download=True,
                                  transform=transform
                                 )

import matplotlib.pyplot as plt

class_names = {
    0: "t-shirt/top",    # 티셔츠/상의
    1: "trouser",        # 바지
    2: "pullover",       # 풀오버 (스웨터)
    3: "dress",          # 원피스
    4: "coat",           # 코트
    5: "sandal",         # 샌들
    6: "shirt",          # 셔츠
    7: "sneaker",        # 운동화
    8: "bag",            # 가방
    9: "ankle boot",     # 앵클 부츠
}

plt.figure(figsize=(10,10))
for i in range(25):
    plt.subplot(5,5,i+1)  # 그래프의 표시 위치
    img, label = train_data[i]
    plt.xticks([])
    plt.yticks([])
    plt.grid(False)  # 그리드선
    plt.imshow(torch.permute(img, (1, 2, 0)), cmap=plt.cm.binary)
    plt.xlabel(class_names[label])
plt.show()

import os
os.cpu_count()

2

batch_size = 32  # batch_size 지정
num_workers = 8  # Thread 숫자 지정

train_loader = torch.utils.data.DataLoader(train_data,
                                           batch_size=batch_size,
                                           shuffle=True,
                                           num_workers=num_workers)

/usr/local/lib/python3.10/dist-packages/torch/utils/data/dataloader.py:558: UserWarning: This DataLoader will create 8 worker processes in total. Our suggested max number of worker in current system is 2, which is smaller than what this DataLoader is going to create. Please be aware that excessive worker creation might get DataLoader running slow or even freeze, lower the worker number to avoid potential slowness/freeze if necessary.
  warnings.warn(_create_warning_msg(

test_loader = torch.utils.data.DataLoader(test_data,
                                          batch_size=batch_size,
                                          shuffle=False,
                                          num_workers=num_workers)

# 1개의 배치 추출 후 Image, label의 shape 출력
img, lbl = next(iter(train_loader))
img.shape, lbl.shape

(torch.Size([32, 1, 28, 28]), torch.Size([32]))

torch.cuda.is_available()

False

device = torch.device("cuda:0" if torch.cuda.is_available() else "cpu")
print(device)

cpu

import torch.nn as nn
import torch.nn.functional as F
import torch.optim as optim

class DNNModel(nn.Module):
    def __init__(self):
        super(DNNModel, self).__init__()
        self.fc1 = nn.Linear(28*28, 128)
        self.fc2 = nn.Linear(128, 32)
        self.output = nn.Linear(32, 10)

    def forward(self, x):
        # 텐서는 같지만 새로운 텐서 반환(모양 변환)
        x = x.view(-1, 28*28)
        x = F.relu(self.fc1(x))
        x = F.relu(self.fc2(x))
        x = self.output(x)
        return x

model = DNNModel() # Model 생성
model.to(device)   # device 로드

DNNModel(
  (fc1): Linear(in_features=784, out_features=128, bias=True)
  (fc2): Linear(in_features=128, out_features=32, bias=True)
  (output): Linear(in_features=32, out_features=10, bias=True)
)

optimizer = optim.Adam(model.parameters(), lr=0.0005)
loss_fn = nn.CrossEntropyLoss()

from tqdm import tqdm

def model_train(model, data_loader, loss_fn, optimizer, device):
    model.train()

    # 초기화
    total_batch_loss = 0   # 총 손실
    total_num = 0          # 정답 개수

    prograss_bar = tqdm(data_loader)

    # mini-batch 학습
    for img, lbl in prograss_bar:
        # image, label 데이터를 device에 올리기.
        img, lbl = img.to(device), lbl.to(device)

        optimizer.zero_grad()  # 그래디언트 초기화
        output = model(img)    # Forward Propagation을 진행. 결과 획득.

        loss = loss_fn(output, lbl) # 손실 계산
        loss.backward()   # 오차역전파(Back Propagation) 진행. 미분 값을 계산
        optimizer.step()  # 가중치 업데이트

        # output의 max(dim=1)은 max probability와 max index를 반환.
        # max probability는 무시하고, max index는 pred에 저장
        _, pred = output.max(dim=1)

        # pred.eq(lbl).sum() 은 정확히 맞춘 label의 합계를 계산합니다.
        # item()은 tensor에서 값을 추출.
        total_num += pred.eq(lbl).sum().item() #

        # 이를 누적한 뒤 Epoch 종료시 전체 데이터셋의 개수로 나누어 평균 loss를 산출합니다.
        # total_batch_loss에 1개 배치의 전체 loss를 더하기
        total_batch_loss += loss.item() * img.size(0)

    acc = total_num / len(data_loader.dataset) # 정확도 계산

    # 평균 손실(loss)과 정확도를 반환합니다.
    # train_loss, train_acc
    return total_batch_loss / len(data_loader.dataset), acc

def model_evaluate(model, data_loader, loss_fn, device):
    model.eval()  # model.eval()은 모델을 평가모드로 설정 변경

    with torch.no_grad():
        # 손실과 정확도 계산을 위한 초기화
        total_num = 0
        total_batch_loss = 0

        # 배치별 evaluation을 진행
        for img, lbl in data_loader:

            # device에 데이터를 올리기
            img, lbl = img.to(device), lbl.to(device)

            output = model(img) # Forward Propagation을 진행. 결과 획득.

            # output의 max(dim=1)은 max probability와 max index를 반환.
            _, pred = output.max(dim=1)
            total_num += torch.sum(pred.eq(lbl)).item()  # 정확한 것 개수 더하기(누적)

            # 이를 누적한 뒤 Epoch 종료시 전체 데이터셋의 개수로 나누어 평균 loss를 산출합니다.
            total_batch_loss += loss_fn(output, lbl).item() * img.size(0)

        acc = total_num / len(data_loader.dataset)  # 정확도 계산

        # 결과를 반환 - val_loss, val_acc
        return total_batch_loss / len(data_loader.dataset), acc

%%time

# epochs 지정, 최소 손실 초기화
num_epochs = 20
min_loss = np.inf

# Epoch 별 훈련 및 검증을 수행합니다.
for epoch in range(num_epochs):
    # 모델 학습 - 학습 손실과 정확도를 얻기
    train_loss, train_acc = model_train(model, train_loader, loss_fn, optimizer, device)

    # 모델 검증 - 검증 손실과 검증 정확도를 얻기
    val_loss, val_acc = model_evaluate(model, test_loader, loss_fn, device)

    # val_loss가 개선시, model의 가중치(weights)를 저장.
    if val_loss < min_loss:
        print(f'[INFO] val_loss 개선 from {min_loss:.5f} to {val_loss:.5f}. 모델 저장!')
        min_loss = val_loss
        torch.save(model.state_dict(), 'DNNModel.pth')

    # Epoch 별 결과를 출력
    print(f"epoch {epoch+1:02d}")
    print(f"loss: {train_loss:.5f}, acc: {train_acc:.5f}", end="   ")
    print(f"val_loss: {val_loss:.5f}, val_accuracy: {val_acc:.5f}")

100%|██████████| 1875/1875 [00:18<00:00, 103.84it/s]

[INFO] val_loss 개선 from inf to 0.47117. 모델 저장!
epoch 01
loss: 0.57661, acc: 0.80183   val_loss: 0.47117, val_accuracy: 0.83260

100%|██████████| 1875/1875 [00:19<00:00, 97.72it/s]

[INFO] val_loss 개선 from 0.47117 to 0.43217. 모델 저장!
epoch 02
loss: 0.40842, acc: 0.85520   val_loss: 0.43217, val_accuracy: 0.84550

100%|██████████| 1875/1875 [00:17<00:00, 105.49it/s]

[INFO] val_loss 개선 from 0.43217 to 0.38365. 모델 저장!
epoch 03
loss: 0.36454, acc: 0.86970   val_loss: 0.38365, val_accuracy: 0.86170

100%|██████████| 1875/1875 [00:18<00:00, 103.90it/s]

[INFO] val_loss 개선 from 0.38365 to 0.37367. 모델 저장!
epoch 04
loss: 0.33754, acc: 0.87740   val_loss: 0.37367, val_accuracy: 0.86350

100%|██████████| 1875/1875 [00:17<00:00, 105.30it/s]

[INFO] val_loss 개선 from 0.37367 to 0.37178. 모델 저장!
epoch 05
loss: 0.31868, acc: 0.88337   val_loss: 0.37178, val_accuracy: 0.86560

# 가중치 로드
model.load_state_dict(torch.load('DNNModel.pth'))

# 최종 검증 손실(validation loss)와 검증 정확도(validation accuracy)를 계산
loss, acc = model_evaluate(model, test_loader, loss_fn, device)
print(f'검증 손실: {loss:.5f}, 평가 정확도: {acc:.5f}')

검증 손실: 0.33344, 평가 정확도: 0.88120

pytorch fashion-mnist 실습¶

학습 목표¶

목차

01 데이터 및 라이브러리 불러오기

Image Transform¶

Fashion MNIST DataSet¶

¶

Fashion MNIST 데이터셋 로드¶

학습용 및 테스트용 데이터 셋 가져오기¶

데이터 시각화¶

02. 데이터를 배치 단위로 가져오기 - DataLoader

train_loader 활용하여 하나의 배치 확인¶

03. 모델 정의 및 구축

최적화함수(optimizer) 및 손실함수(loss function)¶

04. 모델 학습

05. 모델 평가

06. 모델 학습 및 검증

모델의 가중치를 가져와 검증 손실과 검증 정확도를 계산¶

REF¶
